Overview: Architects
An architect designs a building and puts their name and seal on the drawings that get built from. The work moves in stages: working out what you need and what the lot will allow, a concept, schematic design, then construction documents detailed enough for a contractor to price and a building department to review. After that comes permitting, help sorting through bids, and visits during construction to check that what is going up matches what was drawn.
Two things surprise people. The architect is not the engineer. Structural, mechanical and civil work are separate disciplines that get coordinated into the set and billed on top. And the drawings usually remain the architect's property. You receive a license to use them for this project on this site, so ask what happens if you part ways midway.
Whether you legally need one depends on your state. Rules commonly turn on the size, the use and the occupancy of the building, and a stamped set from a licensed architect or engineer is required above those thresholds. A designer or drafter can produce good drawings but cannot stamp them.
Use the state and city lists below to reach firms working in your area.
Cost of Architectural Services
Choose how much design support you need: advice by the hour, a defined drawing package, or design through construction. These are alternative fee models, not charges to add together.
| Service or scope | Planning range | What this covers |
|---|---|---|
| Hourly architectural advice or design | $150–$250per architect hour | One architect working on feasibility, design or approved revisions; agree the deliverable and an estimated number of hours.Included scope and possible extrasScope used for this estimate: Specified professional time Outside this estimate: Consultants; Reimbursable expenses unless included |
| Basic design for a new custom home | 8%–12%of the agreed construction-cost base | Architectural design and construction drawings for a new single-family home; the proposal must list the phases, revisions and consultant scope.Ask what construction-cost figure the percentage uses and whether the fee changes when the budget changes.Included scope and possible extrasScope used for this estimate: Architectural design phases and drawings listed in the agreement Outside this estimate: Land survey and specialist engineering unless included; Permit charges; Construction administration unless included |
| Addition or remodel with construction support | 10%–20%of defined construction cost | A residential addition or substantial remodel with design, drawings and specified bidding and construction-administration services.Specify site visits, contractor questions and review of changes; a drawing-only fee is a different service.Included scope and possible extrasScope used for this estimate: Listed design phases; Specified construction-administration services Outside this estimate: Unlisted consultants; Permit fees; Additional design changes |
What changes the price
- Project size, complexity and existing-condition information
- Design phases, revision rounds and consultant coordination
- Construction site visits and additional-service authorization
Ask before you book
- Which phases and deliverables does the fee cover?Prevents a concept-only fee being compared with full service.
- How is the construction-cost fee base defined and updated?Clarifies which budget changes affect a percentage fee.
- What revisions, consultants and site visits cost extra?Identifies common gaps between a design fee and the final bill.
Check the scope
A percentage fee needs a defined construction-cost base. Engineering, surveys, permit charges and extra revisions may sit outside the architectural agreement.
Compare quotes wisely
Agree deliverables and revision rounds early, and request a fee for each optional phase before adding it.
How to read these estimates
These ranges combine published U.S. prices and cost guidance for the stated work. They are budgeting estimates, not offers from listed companies or a statistical national average. Confirm the total, included work and additional charges in writing.
U.S. planning estimates. Local quotes vary by location and the scope of work.
Frequently asked questions
What happens at each stage of a project?
First the brief and a feasibility check against zoning, setbacks and the site. Then a concept, then schematic design where the plan settles. Construction documents follow, which is the long phase and the one contractors price from. Then permitting, then bidding and negotiation, then contract administration while the building goes up. Ask which of those stages your fee actually covers.
When does a project legally need an architect?
That depends on your state and sometimes your city. Rules usually key off the size, the use and the occupancy of the building, and once a project crosses those lines the permit set has to carry the seal of a licensed architect or engineer. Small residential alterations often fall below the line. Ask your building department directly before you hire anyone, because they apply the rule.
Is structural engineering part of the fee?
Usually not. The architect coordinates the consultants but you engage and pay the structural engineer, and often a civil, mechanical or geotechnical engineer too. Their calculations and details become part of the permit set. Ask at the proposal stage which consultants the project will need and who is holding those contracts, because an unexpected engineering scope is a common surprise.
How are architects' fees structured?
Commonly a share of the construction cost, an hourly rate against a cap, a fixed fee for each phase, or a fee based on floor area. A share of construction cost is simple but rises as the build gets more expensive, so ask how it is recalculated. Ask what counts as an additional service, since a redesign after you change your mind usually does.
Who owns the drawings when the job ends?
The architect normally retains copyright and grants you a license to use the drawings for this project on this site. That license can depend on the fees being paid in full, which matters if a dispute develops. Handing the set to another firm or reusing the design on a second lot generally needs permission. Read the ownership clause before you sign the agreement.
Should I get a feasibility study before buying land?
If the plot is at all unusual, yes. Zoning, setbacks, easements, slope, soil, flood mapping, access and utility connections all decide what can be built, and a lot can look perfect and permit badly. A short feasibility study before closing is cheap next to discovering the constraint afterwards. Many purchase agreements allow a study period for exactly this.
